With years of experience in production Liquid Filtration Multifilament, NETT can supply a wide range of PVDF Multi-Filament. High quality PVDF Multi-Filament can meet many applications, if you need, please get our online timely service about PVDF Multi-Filament. In addition to the product list below, you can also customize your own unique PVDF Multi-Filament according to your specific needs.
With years of experience in production Liquid Filtration Multifilament, NETT can supply a wide range of PVDF Multi-Filament. High quality PVDF Multi-Filament can meet many applications, if you need, please get our online timely service about PVDF Multi-Filament. In addition to the product list below, you can also customize your own unique PVDF Multi-Filament according to your specific needs.
Benefits of our Multi-Filament made of PVDF:
We are a supplier of PVDF Multi Filament, which is made from raw PVDF material that is spun using a POY process. PVDF has high insulation qualities, good chemical resistance, linear UV resistance, and self-extinguishing qualities.
Features of PVDF Multi-Filament:
PVDF in fluorine plastics has the strongest toughness, low friction coefficient, strong corrosion resistance, aging resistance, good weather resistance, good resistance to ultraviolet radiation and so on.
1. toughness, high mechanical strength, and resistance to wear.
2. outstanding resistance to chemicals
3. resistance to weather, UV light, and nuclear radiation.
4. strong dielectric strength and good heat resistance.
The specifications of FLONtex® PVDF Multi-Filament produced by us are 0.15mm-0.9mm.
Type: PVDF Multi-Filament 600D
NO. |
parameter |
Value |
Test Temperature |
Notes |
1 |
Linear density |
660±20dtex |
Ambient temperature |
600 D |
2 |
Breaking strength |
≥13N |
<20ºC |
|
3 |
Breaking tenacity |
≥1.96cN/dtex |
<20ºC |
|
4 |
Elongation at break |
≥10~15% |
<20ºC |
|
5 |
Heat-shrinkage rate |
≤3% |
1300ºC /2h |
|
6 |
Yarn |
48 |
|
|
7 |
Average mass per one meter |
0.066g/m |
|
|
8 |
Color |
Natural color |
|
|
9 |
Net Weight/spool |
50-650g |
|
|
10 |
Thread Diameter |
0.28 |
|
|
Type: PVDF Multi-Filament 1200D
NO. |
parameter |
Value |
Test Temperature |
Notes |
1 |
Linear density |
1350±20dtex |
Ambient temperature |
1200D |
2 |
Breaking strength |
≥24N |
<20ºC |
|
3 |
Breaking tenacity |
≥1.7cN/dtex |
<20ºC |
|
4 |
Elongation at break |
≥10~15% |
<20ºC |
|
5 |
Heat-shrinkage rate |
≤3% |
130ºC /2h |
|
6 |
Yarn |
96 |
|
|
7 |
Average mass per one meter |
0.135g/m |
|
|
8 |
Color |
Natural color |
|
|
9 |
Net Weight/spool |
50-650g |
|
|
10 |
Thread Diameter |
0.05 |
|
|
Textiles used for fishing, knitting, weaving, filtering, and braiding. Advantage: PVDF exhibits the highest toughness, lowest friction coefficient, robust corrosion resistance, aging resistance, weather resistance, and good radiation resistance in fluorine plastics.
1. We can produce various specs including 200D, 300D, 500D 1200D etc.
2. We accept customized PVDF Multi-Filament in various colors. If you need help determining the best yarn or thread specific to your application, please contact us, we would be happy to help!
3. Our products are packed in our own LOGO cartons, each weighing 18kg. We can pack according to the packing details you provided. To ensure the safety and security of the product during transportation, each carton is individually packaged and secured to a plywood pallet. This packaging method ensures that the product remains in good condition and reaches its destination intact.
4. NETTtex® has been aggressively concentrating on technological innovation in order to bring new products to market first and achieve profitable outcomes. As of right now, it has 10 utility models, 1 design patent, and 2 authorized invention patents. The company has become a dominant force in the industry thanks to its creative products.
Moreover, NETTtex® has received acknowledgement for its technological contributions. 2018 saw the company classified as a "Small and medium-sized science and technology enterprise in Jiangsu province." 2019 saw the designation of NETTtex® as a "High-tech enterprise." These honors bear witness to the business's unwavering dedication to remaining at the forefront of innovations and technological advancements.
